Digital Storage Oscilloscopes

GDS-3000A Series Digital Storage Oscilloscopes

GDS-3000A Series Digital Storage Oscilloscopes

  • 650MHz /350MHz Bandwidth, 2 Input Channels
  • 5GSa/s Real-time Sampling Rate(half channels); 2.5GSa/s Real-time Sampling Rate(all channels)
  • Per Channel 200Mpts Memory Depth
  • 200,000 wfm/s of Waveform Update Rate

MDO-2000A Series Mixed-domain Oscilloscopes

MDO-2000A Series Mixed-domain Oscilloscopes

  • 300/200/100MHz bandwidth selections ;2 channels
  • Real time sampling rate is 2GSa/s max.
  • Per Channel 20M memory depth and VPO waveform display technology
  • Waveform update rate up to 120,000 wfms/s

GDS-3000 Series Digital Storage Oscilloscopes

GDS-3000 Series Digital Storage Oscilloscopes

  • 500/350/250/150MHz with 2/4 Channels
  • 5GSa/s RT or 100GSa/s ET Sampling Rate
  • Independent Memory for Each Channel
  • Serial Bus Analysis Software for I2C, SPI and UART (Optional)

GDS-2000A Series Digital Storage Oscilloscopes

GDS-2000A Series Digital Storage Oscilloscopes

  • 300MHz/200MHz/100MHz/70MHz Bandwidth ,2 or 4 Input Channel
  • 2GSa/s Real-time Sampling Rate and 100GSa/s Equivalent Time Sampling Rate
  • 8 inch 800*600 High Resolution TFT LCD Display
  • 1mV /div to 10V/div of Vertical Range

MSO-2000E Series Mixed-signal Oscilloscopes

MSO-2000E Series Mixed-signal Oscilloscopes

  • 200/100/70MHz bandwidth selections: 2 or 4 channels
  • MSO-2000E equips with a 16-channel logic analyzer
  • Waveform update rate up to 120,000 wfms/s
  • Maximum 10M memory depth and VPO waveform display technology

MDO-2000E Series Mixed-domain Oscilloscopes

MDO-2000E Series Mixed-domain Oscilloscopes

  • 200/100/70MHz bandwidth selections ; 2 or 4 channels
  • Real time sampling rate for each channel is 1GSa/s (2 channel models)
  • Maximum real time sampling rate is 1GSa/s (4 channel models)
  • Per Channel 10M memory depth and VPO waveform display technology

GDS-2000E Series Digital Storage Oscilloscopes

GDS-2000E Series Digital Storage Oscilloscopes

  • 200/100/70MHz Bandwidth Selection; 2 or 4 Channels
  • 1GSa/s Real-Time Sampling Rate for Each Channel (2ch model) ; 1GSa/s Maximum Real-Time Sampling Rate (4ch model)
  • Per Channel 10M Memory depth and VPO Waveform Display Technology

GDS-1000B Series Digital Storage Oscilloscopes

GDS-1000B Series Digital Storage Oscilloscopes

  • 200/100/70MHz bandwidth selections, 2ch input
  • 100/70/50MHz bandwidth selections, 4ch input
  • 1GSa/s maximum sampling rate
  • 10M maximum memory depth for each channel
